Colenta DX Easy HighCap Xr Readar

(0 reviews)

Colenta Computed Radiography

Brand: Colenta

Type: CR Reader HighCap Xr

Origin: Austria

Warranty: 1 Year

Category: Diagnostic

Subcategory: No Subcategory

Tags: #Colenta Cr X ray machine #Colenta X -ray machine #CR Reader HighCap Xr

700,000.00 BDT 750,000.00 BDT

Processing Capacity

Up to 47 IPs/hr in size 14“x17“ (35cmx43cm). The Colenta DX Easy Imaging CR Retrofit Kit HighCap Xr is a table-top reader unit that boasts a world-class high processing speed of 73 IPs/hour*. As with all Colenta equipment, the DX Easy Imaging CR Retrofit Kit HighCap Xr is easy to operate. It will help to reduce patient waiting time and greatly increase the efficiency of the examination workflow.

*) The above value is for IPs of 8” x 10” (18cmx24cm)

Reading Resolution – Pixel Size

One of the reader’s key components is the Imaging Plate, or IP, which is used instead of the X-ray film to easily digitize X-ray images.

Space-Saving Design

All of Colenta’s equipment the Colenta DX Easy Imaging CR Retrofit Kit HighCap Xr is easy to operate. It will help to reduce patient waiting time and greatly increase the efficiency of the examination workflow.

The minimum requirement of PC is core i5 processor with 3.2 GHz clock speed & 4GB RAM. 2 x 500 GB SATA Harddisk & RAID supported motherboard are required. 2 x GBit LAN Controller and VGA graphic controller with 24bit color depth.

Description of Computed Radiography X-Ray – CR Reader HighCap Xr

Computed Radiography X-Ray, better known as CR X-Ray, is an x-ray equipment used to process image digitization using photostimulable plates or sheets for image data acquisition. The information produced by the X-Ray examination is in the form of an image that is printed on a cassette or film. Information stored on tape or film is scanned by a CR-Reader and uses DX-Easy Imaging Acquisition software to view x-ray images on a computer. Its purpose is to allow radiologists to improve and test the images to see if they match exactly what is needed to make a proper diagnosis. Images can be exported to various media such as CDs, and flash drives.

Specification:

HEAVY	39 kgs
DIMENSIONS	590 × 540 × 392 mm
BRAND	Colenta
TYPE	CR Reader HighCap Xr
CATEGORY	X-Ray Equipment Computed Radiography or CR
IMAGE PLATE	14” x 17” (35 x 43 cm), 14” x 14” (35 x 35 cm), 10” x 12”, 8” x 10, 24 x 30 cm, 18 x 24 cm, 15 x 30 cm
PROCESSING CAPACITY	14” x 17” up to 47 IPs/hr 18 x 24 cm up to 73 IPs/hr
PIXEL SIZE	100um
POWER SUPPLY CONDITIONS	Single phase 50-60Hz, AC120-240V±10%
WARRANTY	1 year
COUNTRY OF ORIGIN	Austria
